X-i75
A Classic High Performance Class A/B Stereo Integrated Amplifier with digital inputs and Hi-Res DAC
Description
A Classic High Performance Class A/B Stereo Integrated Amplifier with digital inputs and Hi-Res DAC
A versatile performer with both analog and digital inputs, benefiting from the latest technical innovations.
With onboard toroidal transformer and high current design, a dynamic and smooth power plant that can produce fine details in its playback.
The "Hi Bias" operating mode enables Class A operation on the first few watts.
The included system remote can command an entire Advance Paris system.
Further information
Output power 8Ω |
2 x 75W RMS |
---|---|
Output power 4Ω |
2 x 110W RMS |
Bandwidth |
(-3dB) 10Hz-35kHz |
Tone |
+/- 10 dB |
Distortion |
<0.1% |
Signal to noise ratio |
> 90 dB |
Channel separation |
> 70 dB |
Impedance d'entrée |
47KΩ |
Phono input impedance |
47KΩ |
Lvl. amplifier input |
< 300mV |
Phono MM/MC input level |
2,5mV |
Mains voltage |
115-230V |
consumption max. |
300w |
Transformer |
1 |
Height |
120 mm |
Width |
430 mm |
Depth |
320 mm |
Net weight |
8,6 Kg |
CD input |
1 |
Tuner input |
1 |
Auxiliary Input |
4 |
RCA Analog Input |
1 |
Record output |
1 |
Output for Subwoofer |
1 |
Amp-Preamp |
Preamp Output |
Optical input |
1 |
USB-A input |
1 |
USB-B input |
1 |
Output Pair of speakers |
1 |
5 Volt Output WTX 500 |
1 |
Settings |
Treble, Balance, Bypass, Hi Bias Switch, Bass, Volume |
