Overview
Enjoy incredible 8K video and immersive 3D audio from the AVR-X2800H. Fill medium-size rooms with more refined sound from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, wirelessly stream online music and share with HEOS-enabled speakers in other rooms.
Key Features
- Powerful sound : Fill a medium-size room withpowerful, more refined sound.
- Immersive 3D audio: Feel fully enveloped in yourmusic or movie sound.
- Geared for 8K: Enjoy amazing video qualityfrom the latest 8K technologyavailable.
- Music streaming throughoutyour home: With HEOS® Built-in, easilyaccess streaming music andshare with HEOS-enabledspeakers in other rooms.
Specifications
Multichannel SurroundDTS HD Master, DTS:X, DTS:X Pro
o, o,
DTS Neo:X, DTS Neural:X
-,
DTS Virtual:X
IMAX Enhanced
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music
o, o, o,
Dolby ProLogic Ilz, Dolby Surround
-,
Auro 3D
360 Reality Audio/MPEG H
Multichannel Stereo
Max Number of Processing (Preamp) Channels
7.1
Sound Enhancements
Network
HDMI
Multiroom / CI
Others
Inputs/Outputs
Specifications
General
Maximum Dimensions
Weight in kgs
Mono Block Power Amp Construction
Discrete Power Amplifier
D.D.S.C. HD Digital
Pure Direct
Gold Plated RCA Terminals
Clock Jitter Reducer
Alpha Processing
Audyssey
MultEQ XT
Audyssey Dynamic EQ, Dynamic Volume
o,
Audyssey LFC
Dirac Live Upgradability
Compressed Audio Restorer
Media Server
HEOS Wireless Multi-Room Technology
Alexa/Google Voice Assistant/Apple HomePod
o, o,
Lossy Formats: MP3, WMA, AAC
o, o,
Lossless Formats: FLAC, ALAC, WAV
o, o,
Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit)
o, o,
DSD Audio Streaming
(2.8/5.6MHz)
AirPlay 2
TuneIn
Spotify Connect
Pandora
SiriusXM
Roon Tested
HEOS App Control
Compatible with Remote APP for Smart Phones
Denon 2016 AVR Remote
Ethernet Ports
Wi-Fi
Bluetooth
HDMI Inputs: Back, Front
6,
HDCP2.3 support
HDMI Outputs: Main, Zone
2,
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB
o,
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR
, o, o, o,
ALLM (Auto Low Latency Mode) Pass-Through for Gaming
Variable Refresh Rate, Quick Flame Transport, Quick Media Switching
o, o,
3D Signal Pass-through
8K Signal Pass-Through, Scaling, GUI Overlay
o, o,
DSD Audio Capability
Audio Return Channel (ARC), Enhanced ARC
o,
Auto LipSync
Multi-Room Zones
2
Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog
(2ch), (2ch), o,
Zone Audio Output: Speaker, Pre-Out
o,
Zone HDMI Output from HDMI Source
IP Control, RS232 Control, Web Control, App Control
o, /o,
Remote In / Out
o,
DC Trigger Output
HDMI Diagnostics
Auto Speaker Setup by Microphone
Audyssey MultEQ XT
Front Display
1-Line FLD
GUI Languages
3
Setup Assistent
Quick Select Plus, Quick Select
o,
Variable Crossover
Optimized Bass Redirection
Bass Sync
ECO Mode
Auto Power Off
Sleep Timer
HDMI In / Out
6, 2
Multi-room Video Out: Video / HDMI
-,
Analog In, Out
4,
Phono (MM) In
Digital In: Optical / Coaxial
2, 1
Multi-room Out: Analog / Digital
1,
Multichannel Preout
(0.2)
Subwoofer Out
2
Speaker Terminal: Gold Plated Screw / Regular Screw
-,
Number of Speaker Terminals
7
Speaker A / B
Assignable
Bi-amp Drive
Assignable
Multi-Room Speaker Terminal
Assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB
-, -, -, -,
USB Audio / Made for iPod / Made for iPhone
o, -,
AM/FM Tuner
Number of Poweramps
7
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
95W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)
125W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)
185W
Metal Front Panel
System Remote Control
RC-1253
Pre-programmed / Learnable / LCD Display
-, -,
Power Consumption in W
500
Power Consumption No-Sound (ECO On / Off) in W
35W/75W
Standby Consumption in W
0.1
CEC Standby Consumption in W
0.5
Network Standby Consumption in W
Less than 2.0
Maximum Dimensions
Antenna:Horizontal: (W x D x H) in mm
Antenna:Vertical: (W x D x H) in mm)
【w/o Antenna: (W x D x H) in mm】
434 x 340 x 168
( 434 x 340 x 236 )
【 434 x 330 x 168 】
Weight in kgs
9.6
Weight in kgs (Packaging)
11.6
