DENON AVC-X3800H 9.4CH AV RECEIVER WITH 8K VIDEO AND 3D AUDIO

Vendor

DENON

Regular price
$1,999.00
Sale price
$1,999.00
Regular price
$2,499.00
Sold out
Unit price
per
Tax included.

AVC-X3800H

Overview

With nine channels of amplification, up to four independent subwoofers, Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro 3D, the AVC-X3800H envelops larger living spaces in theater-quality sound. Enjoy amazing 8K video quality and with HEOS® Built-in, wirelessly stream and share online music between rooms.

Key Features

  • Enveloping 3D audio: Feel like you're in the center of the action with enveloping 3D sound.
  • Expert ready: You'll be amazed at the available configuration options to best fit your space.
  • Geared for 8K: Enjoy amazing video quality from the latest 8K technology available.
  • Optimize for your room: Enhance performance with room correction options from Audyssey (installed) or Dirac Live (optional upgrade available with future SW update).

High performance nine-channel amplifier

Discrete high-current amplifiers deliver up to 105W per channel (at 8 ohms, 20-20kHz, THD 0.08%)?enough power to drive any speaker.


Dolby Atmos

Feel every dimension in Dolby Atmos. Upgrade your home theater with height speakers to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensation from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without height speakers. You can also enjoy Dolby Atmos music tracks available from Apple Music, Amazon HD andTIDAL and a compatible streaming device.



DTS:X

DTS:X immersive audio sound where it would naturally occur in space, creating lifelike, multi dimensional audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content. DTS Virtual:X provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1, or 2.1speaker setup.



IMAX Enhanced

Get the most premium at-homeentertainment experience withIMAX Enhanced?the latesttechnology from DTS that sets anew standard for home theaterimaging, sound, scale, andclarity. See clearer pictures andbrighter images. Feelimmersive, heart-poundingaudio and experience premiumcontent digitally remastered byIMAX. You can enjoy IMAX Enhancedexperience starting from 5.1.4speaker setup. IMAX Enhancedcompatible TV or projector isrequired.



Auro 3D

Auro 3D elevates the hometheater experience to amazingnew levels by delivering theexcitement of threedimensionalsound for music,games, broadcast, and films,putting you in a cocoon of lifelikesound. Turn your existingaudio-visual collection into anAuro 3D experience, thanks tothe Auro-Matic upmixingengine. Supports up to 7.1.4.Auro 3D speaker configurationwith an external 2 channelamplifier.



360 Reality Audio

360 Reality Audio is a new immersive music experience that uses Sony‘s 360 Spatial Sound technology. Individual Sounds such as vocals, chorus, piano, guitar, bass and even the sounds of the live audience can be placed in a 360 spherical sound field. With 360 Reality Audio, music has never been so immersive and so real.Select Denon AV receivers are capable of 360 Reality Audio playback by connecting a 360RA streaming device via HDMI. Stay tuned for further updates!



HDMI Connectivity with ARC/eARC

Supports the latest technologyon all HDMI inputs and output.ARC (Audio Return Channel) oreARC (Enhanced Audio ReturnChannel) makes playing TVaudio through your AV receiversimple, with just a single HDMIconnection.eARC provides HD and 3D audiotransmission such as DolbyTrueHD, DTS HD Master Audioand Dolby Atmos while ARC islimited to conventional 5.1chaudio formats or PCM.



8K / HDCP 2.3

Enjoy pristine 8K picture qualityon your 8K TV or projector.Supports both 8K pass-throughand 8K upscaling of 4K content.Supports HDCP 2.3, the latestcopy protection standard, forpeace of mind when streamingcopy protected content.



Brilliant color from HDR 10+

Supports HDR (High DynamicRange), HLG (Hybrid LogGamma), as well as DynamicHDR and HDR10+ pass-through.HLG offers HDR technology overbroadcast content. BothDynamic HDR and HDR10+ usedynamic metadata to optimizeshadows and highlights asscreens change.



Dolby Vision

Dolby Vision is a stunning HDRimaging technology that bringsextraordinary color, contrast,and brightness to the screen.Compatible with Dolby Vision soyou can enjoy Dolby Visioncontent from a compatiblesource device and TV.



Next-generation gaming

Supports Variable Refresh Rate(VRR), Quick Frame Transport(QFT) and Auto Low LatencyMode (ALLM) for smooth, lagfreegaming experience whenconnected with the compatiblegaming devices.



HEOS Built-in

With HEOSR Built-in, your AVreceiver can stream musicwirelessly across compatibleHEOS components from avariety of free and premiumstreaming services. Consumerscan also enjoy their favoritemusic in any room of the homewirelessly. Play the same songin every room or select adifferent song for eachconnected room via a variety ofstreaming sources. Add DenonHome speakers to more roomsand control it all with the HEOSapp.



High-resolution audio

Discover the incredible fidelityof high-resolution audio tracksand enjoy music as the artistintended. A front USB portsupports up to 24bit/192kHz hiresaudio playback from a USBdrive. Supported audio formatsare MP3, WMA, WAV, MPEG-4/AAC, FLAC, and ALAC.



Denon Setup Assistant

Award-winning guide DenonSetup Assistant supplies simple,clear instructions to get started.Just connect your AV receiver toyour TV and follow theinstructions on the TV screen toconnect your speakers, performspeaker measurements, andconnect source devices. Foradditional convenience, the AVreceiver renames HDMI inputsautomatically when connectedor you can rename manually atyour convenience.



Audyssey MultEQ Editor app

You can go even further withthe Audyssey MultEQ Editorapp, going “under the hood” toview and adjust settings fordetailed tuning?allowing youto customize the sound moreprecisely to the specificproblems in your room, andtailor the sound to yourpersonal preferences. With thiscomprehensive app, you canharness the power of AudysseyMultEQ to take total control ofthe way your home cinemasounds. The app is available forpurchase in iOS and Google Playstores.



11-channel processing, 9- channel amplification

9-channel amplification doesnot mean you need to stop atmax 11 channel speakerconfiguration. With external 2-channel amplification that canbe assigned to either Front,Left, and Right, or a pair ofheight channels, you can setupan 11-channel speakerconfiguration such as 7.1.4,allowing you even moreflexibility and an engulfingaudio experience.



Subwoofer outputs & settings

Blanket yourself in evenlydistributed, accurate bass.Featuring up to four subwooferoutputs to smooth out lowfrequencies and provide betterdispersion. No audible peaks ordips ? just powerful, roomfillingbass.Tweak your subwoofer settingsto your preference when morethan two subwoofers areconnected. Select "Standard" ifyou want evenly distributedbass performance. Select"Directional" if you want moredirectional bass performanceseamlessly integrated into thespeaker channel closest to eachsubwoofer in the room.



Pre-Amplifier Mode

Your Denon AV amplifier can work as a perfect AV preamplifierwith the latest HDMIconnectivity. Pre-AmplifierMode provides a cleaner signalpath and more tolerance inclipping level by disconnectinginternal amplifiers.Add the flexibility to disconnectselect speaker channels so thatyou can use the AV receiver'sbuilt-in amplification to drivenon-critical channels to get aclearer signal path for thechannels driven by externalamplification.

Dirac Live upgradeability

The interaction between yoursound system and the physicallayout of your room has a hugeimpact on sound quality. DiracLiveR Room Correction (comingsoon in 2023) applies state-of-the-art, patented algorithms toanalyze and digitally reduceroom impact and enhancespeaker performance.Select Denon AV receiverssupport Dirac LiveUpgradability. You can purchasea Dirac Live license key tounlock the functionality. Visitdirac.com/denon/ for moreinformation. Upgradability willbe supported via a futurefirmware update. Stay tuned!



Specifications

Multichannel Surround

DTS HD Master, DTS:X, DTS:X Pro

o, o, -

DTS Neo:X, DTS Neural:X

-, o

DTS Virtual:X

o

IMAX Enhanced

o

Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music

o, o, o, o

Dolby ProLogic Ilz, Dolby Surround

-, o

Auro 3D

o

360 Reality Audio/MPEG H

o, o

Multichannel Stereo

o

Max Number of Processing (Preamp) Channels

11.4



 Sound Enhancements

Mono Block Power Amp Construction

-

Discrete Power Amplifier

o

D.D.S.C. HD Digital

-

Pure Direct

o

Gold Plated RCA Terminals

-

Clock Jitter Reducer

-

Alpha Processing

-

Audyssey

MultEQ XT32

Audyssey Dynamic EQ, Dynamic Volume

o, o

Audyssey LFC

o

Dirac Live Upgradability

o

Compressed Audio Restorer

o

Network
Media Server

o

HEOS Wireless Multi-Room Technology

o

Alexa/Google Voice Assistant/Apple HomePod

o, o, o

Lossy Formats: MP3, WMA, AAC

o, o, o

Lossless Formats: FLAC, ALAC, WAV

o, o, o

Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit)

o, o, o

DSD Audio Streaming

o (2.8/5.6MHz)

AirPlay 2

o

TuneIn

o

Spotify Connect

o

Pandora

o

SiriusXM

o

Roon Tested

o

HEOS App Control

o

Compatible with Remote APP for Smart Phones

Denon 2016 AVR Remote

Ethernet Ports

o

Wi-Fi

o

Bluetooth

o

HDMI
HDMI Inputs: Back, Front

6, -

HDCP2.3 support

o

HDMI Outputs: Main, Zone

2, 1

HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB

o, o

HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR

o , o, o, o, o

ALLM (Auto Low Latency Mode) Pass-Through for Gaming

o

Variable Refresh Rate, Quick Flame Transport, Quick Media Switching

o, o, -

3D Signal Pass-through

o

8K Signal Pass-Through, Scaling, GUI Overlay

o, o, o

DSD Audio Capability

o

Audio Return Channel (ARC), Enhanced ARC

o, o

Auto LipSync

o

Multiroom / CI
Multi-Room Zones

2

Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog

o (2ch), o (2ch), o, o

Zone Audio Output: Speaker, Pre-Out

o, o

Zone HDMI Output from HDMI Source

o

IP Control, RS232 Control, Web Control, App Control

o, o /o, o

Remote In / Out

o, o

DC Trigger Output

1

HDMI Diagnostics

o

Others
Auto Speaker Setup by Microphone

Audyssey MultEQ XT32
Dirac Live (upgrade)

Front Display

1-Line FLD

GUI Languages

3

Setup Assistent

o

Quick Select Plus, Quick Select

o, -

Variable Crossover

o

Optimized Bass Redirection

o

Bass Sync

o

ECO Mode

o

Auto Power Off

o

Sleep Timer

o

Inputs/Outputs
HDMI In / Out

6, 3

Multi-room Video Out: Video / HDMI

-, o

Analog In, Out

5, -

Phono (MM) In

o

Digital In: Optical / Coaxial

2, 2

Multi-room Out: Analog / Digital

1, -

Multichannel Preout

o (11.4)

Subwoofer Out

4 (independent)

Speaker Terminal: Gold Plated Screw / Regular Screw

-, o

Number of Speaker Terminals

11

Speaker A / B

Assignable

Bi-amp Drive

Assignable

Multi-Room Speaker Terminal

Assignable

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB

-, -, -, -, o

USB Audio / Made for iPod / Made for iPhone

o, -, -

AM/FM Tuner

o

Specifications
Number of Poweramps

9

Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)

105W

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)

-

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)

135W

Power Output (6 ohm, 1 kHz, 10% 1ch Drive)

215W

General
Metal Front Panel

-

System Remote Control

RC-1253

Pre-programmed / Learnable / LCD Display

-, -, -

Power Consumption in W

660W

Power Consumption No-Sound (ECO On / Off) in W

60W/100W

Standby Consumption in W

0.1

CEC Standby Consumption in W

0.5

Network Standby Consumption in W

Less than 2.0

Maximum Dimensions
Antenna:Horizontal: (W x D x H) in mm
Antenna:Vertical: (W x D x H) mm)
【w/o Antenna: (W x D x H) in mm】

434 x 389  x 168
( 434 x 389 x 236 )
【 434 x 378 x 168 】

Weight in kgs

12.5

Weight in lbs (Packaging)

15.1
