ISOTEK EVO3 TITAN 2 OUTLET HIGH CURRENT POWER CONDITIONER

ISOTEK

$7,499.00

EVO3 Titan

The new EVO3 Titan is a progression of IsoTek’s original multi-award winning design. Whilst utilising the unique Direct-Coupled© technology, the circuit has been radically updated. EVO3 Titan offers the ultimate high current/ power conditioner in the smallest form factor.

  • Removes both Common Mode and Differential Mode mains noise.
  • RFI reduction 82dB (50 ohms standard), down to 5Hz frequency range.
  • Unique nine-stage conditioning network in a series parallel configuration, that delivers extremely low-impedance and high-current power. An increase of 20% Differential Mode and 600% Common Mode filtering compared to the original GII Titan. 50% of the 40A Super Titan circuit reconfigured to 20A.
  • KERP© (Kirchoff’s Equal Resistance Path) ensures equal resistance and equal power delivery across all outlets.
  • 112,500A of instantaneous protection, featuring IsoTek’s unique sequential protection system with earth fault protector.
  • Internal wiring; solid core silver plated PCOCC with FEP virtually an air dielectric.
  • Two independent outlets deliver 4,600W continuous power with 25,000W transient ability (supply permitting).
Number of outlets 2 + Multi-Link
Type of outlets  AU
Mains inlet C20 IEC
Mains voltage 100-240VAC/50-60Hz
Maximum current 20Amps continuous
Total power (nominal 230V) 4600W
(Circuit/Transient) 4600W/25,000W
Dimensions 275 x1 82.5 x 275mm (W x H x D)
