JBL

JBL HDI 4500 CENTRE SPEAKER

JBL HDI 4500 CENTRE SPEAKER

Regular price $3,499.00
Regular price Sale price $3,499.00
Sale Sold out
Taxes included.

Quadruple 5.25-inch (130mm) 2 ½-way Center Channel Loudspeaker

Designed and engineered in JBL’s world-famous acoustic engineering facility in Northridge, California, the HDI-4500 is the anchor of a complete HDI Series surround system. This center channel loudspeaker features a 2 ½-way design with patented High-Definition Imaging (HDI™) waveguide technology, the patented 2410H-2 1-inch (25mm) compression driver, and quadruple 5.25-inch (130mm) Advanced Aluminum Matrix cone woofers for powerful dynamics and incredibly accurate sound reproduction. The HDI-4500 enclosure is heavily braced to provide a solid acoustic foundation, and incorporates a bass reflex design with dual rear-firing, computer-optimized flared ports. The sophisticated curved cabinet features a modern design finished in a choice of automotive-grade painted High Gloss Black, or furniture-grade satin Walnut. A black cloth, magnetically attached grille completes the elegant appearance.



HDI-4500 Highlights

  • Patented HDI™ (High-Definition Imaging) waveguide technology
  • Patented 2410H-2 high-frequency compression driver
  • Quad 5.25-inch (130mm) cast frame, Advanced Aluminum Matrix cone woofers with 1.5-inch voice coils
  • Contemporary design with premium finishes including high-gloss Black, and satin Walnut wood veneer

General Specifications

Enclosure Type Bass-reflex design with rear-firing port
High Frequency Transducer 1-inch (25mm) Teonex compression driver
Low / Mid Frequency Transducers Four 5.25-inch (130mm) black Advanced Aluminum Matrix cone, cast frame woofers
Crossover Frequency 600Hz, 2200Hz
Sensitivity (2.83V @ 1M) 90dB
Nominal Impedance 4 Ohm
Recommended Amplifier Power 20W – 250W
Frequency Response 50Hz – 30kHz (-6dB)
Dimensions (H x W x D) 7.48 x 33.13 x 12.3” (190 x 841.4 x 312.5mm)
Net Weight 44.33 lbs (20.11kg)
