"Sit anywhere" Uni-Q sound
At the heart of the evolved Q Series is the Uni-Q driver array. The signature innovation places the tweeter in the acoustic centre of the midrange and bass cone, bringing the acoustic ideal of a single point source closer than ever to realisation. The result is a more detailed, accurate three-dimensional sound image, which is dispersed more evenly throughout the room than is possible with any conventional speaker. Uni-Q's ultra-wide dispersion is further enhanced through KEF's 'tangerine' waveguide over the tweeter dome.
Damped tweeter loading tube
With the addition of the damped tweeter loading tube providing a gentle termination of sound produced from the back of the tweeter, lower treble performance is improved dramatically and a new low-distortion inductor on the crossover provides cleaner bass.
New system design
The closed box midrange cabinet design reduces the load on the Uni-Q midrange cone, increasing clarity and detail while delivering cleaner, punchier bass. Midrange clarity is enhanced again through improvements to the mid-bass driver that allowed the DC blocking capacitor to be eliminated. Its removal also created a more natural bass roll-off between the drivers.
Beefier LF drivers and ABRs
Low-frequency (LF) drivers now have a larger roll surround, along with a new suspension to produce cleaner bass at high volumes. A new cone structure improves midrange clarity, and an enhanced Auxiliary Bass Radiator (ABR) with a new surround and rear suspension delivers better controlled and more impressive bass.
Design |
Two and a half-way bass reflex |
---|---|
Drive Units | 165mm (6.5in.) aluminium Uni-Q 25mm (1in.)vented aluminium dome HF 165mm (6.5in.) aluminium LF 2 x 165mm (6.5in.)aluminium ABR |
Frequency range free field | 42Hz (-6dB) |
Frequency Response | 48Hz-28kHz (±3dB) |
Crossover Frequencies | 2.5kHz |
Maximum Output | 111dB |
Amplifier requirements | 15-150W |
Sensitivity | 88dB |
Nominal Impedance | 8 Ohms (min.3.8 Ohms) |
Dimensions | H x W x D: 923 x 210 x 306 mm 977 x 323 x 310 mm (with Plinth) |
Weight | 16.5kg (36.4lbs) |
