Audiophile “All-in-one Plug & Play“ turntable system
All-in-one Plug & Play system!
Juke Box E1 is a record player, phono stage, BT receiver, line pre-amplifier and power amplifier in one, requiring only a pair of speakers to make a complete system. If you thought that a starter turntable system is complicated to set up, Juke Box E1 proves the contrary. This belt-drive deck offers the fastest possible installation process because it comes pre-adjusted out of the box and offers superb sound quality. Tracking force and anti-skating is pre adjusted for the pre-mounted Ortofon OM 5E cartridge.
In the box:
- Juke Box E1 with Ortofon OM 5E cartridge
- Remote control incl. batteries
- Felt mat
- Dust cover
- Adapter for 7“ singles
- Power supply
- Allen key, stylus pressure gauge, gloves
Features
- NEW reworked tonearm design & new headshell
- NEW anti-resonant ABS polymer main platter
- NEW damped DC motor
- NEW electronic speed change
- Instant playback with super-easy setup
- High contrast display on top
- BT and 1 line input
- Line output (record player signal only)
- Gold plated sockets
- Pre-adjusted tracking force & anti-skating force
- Ortofon OM5e cartridge, pre-mounted
- 8.6” aluminium tonearm with sapphire bearings
- Belt drive with silicone belt
- Special feet for effective decoupling
- IR remote control included
- Colour options: HG Black, HG White, HG Red, Walnut
Technical Specifications
Power output | 2 x 50 Wats (4 Ohm) |
Outputs | Speakers, Line out (fixed, record player signal only), Phono out |
Inputs | BT, 1x Line (analogue) |
Speed | 33, 45 (electronic speed change) |
Principle | Belt drive |
Speed variance | 33: 0.7% 45: 0.6% |
Wow & flutter | 33: 0.25% 45: 0.23% |
Platter | 300mm anti-resonant ABS polymer with feltmat |
Main bearing | Stainless steel in bronze bushing |
Tonearm | 8.6” aluminium |
Effective arm length | 218.5 mm |
Overhang | 22.0 mm |
Effective tonearm mass | 7.0 g |
Included accessory | Power supply, dust cover, remote control, feltmat, singles adapter |
Power consumption | 110W max |
Dimensions | 415 x 118 x 334mm (WxHxD) |
Weight | 5 kg net |
