Stream your turntable wirelessly

Wireless Bluetooth 5.2 streaming with aptX Adaptive and HD of built-in Phono preamplifier and additional line source

After the big success of our VT-E BT we decided to create a phono preamplifier that turns any turntable (with moving magnet cartridge) into a modern Bluetooth streamer.

Phono Box E BT5 offers two separate inputs, a phono and a line level input, as well as two separate outputs. It can be used as an ordinary MM phono stage that connects to any hifi amplifier via its line level output (3.5 mm jack) or it can be used as a Bluetooth streamer. It takes the provided analogue input signal, converts it and sends digital audio to any Bluetooth receiver within a 10 m range. Those devices could be either Bluetooth headphones, speakers or any other Bluetooth receiver.

Phono Box E BT5 is the perfect companion for all modern audiophiles who want to enjoy their vinyl hobby with the comfort of wireless streaming and in high-definition! Bluetooth 5.2 together with aptX Adaptive and aptXHD enables high-resolution formats in audiophile quality.

The Phono Box E BT5 is best paired with our BT Box E HD to ensure high-resolution transmission compatibility!



Features

  • Connect your turntable wirelessly
  • Bluetooth 5.2 streaming with aptX Adaptive and HD support
  • 2 Inputs: 1 Phono and 1 Line Input
  • Suitable for MM cartridges
  • Precise RIAA equalisation
  • Use analogue RCA & BT output simultaneously
  • Low noise circuitry
  • Internal metal shielding
  • Gold-plated RCA connectors
  • Outboard power supply included
  • Colour options: black or white




Technical Specifications



Phono input impedance 47 kohms
Phono capacitance 100 pF
Gain phono 34 dB
Inputs 1 Phono (RCA), 1 Line In (3.5 mm)
Outputs 1 Line Out (3.5 mm), 1 Bluetooth
Noise floor 74dbA (A-weighted)
THD < 0,04%
Phono/Line in max. input voltage 800mV
RIAA equalisation curve accuracy within 0.5 dB/20 Hz - 20 kHz
Bluetooth V5.2, aptX, aptX Adaptive, aptX HD
Outboard power supply 18 V/500 mA DC, suitable for your country's mains supply
Power consumption 200 mA DC
Dimensions W x H x D (D with sockets) 120 x 32 x 100mm
Weight 280 g without power supply
