ROTEL A10MKII INTEGRATED AMPLIFIER
ROTEL A10MKII INTEGRATED AMPLIFIER
ROTEL A10MKII INTEGRATED AMPLIFIER
  • Load image into Gallery viewer, ROTEL A10MKII INTEGRATED AMPLIFIER
  • Load image into Gallery viewer, ROTEL A10MKII INTEGRATED AMPLIFIER
  • Load image into Gallery viewer, ROTEL A10MKII INTEGRATED AMPLIFIER

ROTEL A10MKII INTEGRATED AMPLIFIER

Vendor

ROTEL

Regular price
$879.00
Sale price
$879.00
Regular price
Sold out
Unit price
per
Tax included.



A10MKII

The A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience. Constructed with a massive Rotel-built toroidal transformer, the A10MKII delivers 50 Watts per channel of Class A/B power into 8 ohms featuring three RCA inputs and a Moving Magnet Phono stage for vinyl lovers.


Power 2 x 50 Watts of robust power, 8 Ω

Remote ControlIncludes remote control

TurntableMoving Magnet Phono input for turntable connection

Class AB amplifier design

 High current power supply

Engineered with care.


Dimensions (W × H × D)
430 × 73 × 347mm
17” x 2 7/8” x 13 5/8”

Front Panel Height
60 mm (2 3/8”)

Power Requirements
230V, 50Hz

Power Consumption
150W

Standby Power Consumption
<0.5W

Net Weight
6.6 kg, 14.5 lbs

BTU Rating (4Ω, 1/8th power)
450 BTU/h

Components

Power Output
50W/Ch (All channels driven, 8Ω)

Total Harmonic Distortion (THD)
<0.03%

Frequency Response
Line Level Inputs: 10Hz - 100kHz, -0.5dB, +0.05dB
Phono Input: 20Hz - 20kHz, -0.5dB, +0.3dB

S/N Ratio (IHF "A" Weighted)
Line Level Inputs: 90dB
Phono Input: 85dB



Product Description

The A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience.

Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A10MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher into more challenging loudspeakers.

All analog sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.

An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analog volume controller extend ease of use to the listening seat.

The A10MKII is available in both black and silver colors.



More Specifications
Intermodulation Distortion (60Hz:7kHz, 4:1)
<0.03%

Damping Factor
120

Input Sensitivity
Line Level Inputs: 120mV
Phono Input (MM): 1.5mV

Input Impedance
Line Level Inputs: 45kΩ
Phono Input (MM): 43kΩ
Input Overload
Line Level Inputs: 4V
Phono Input: 50mV


Tone Controls
±6dB at 100Hz / 10kHz
