ROTEL RA-6000 DIAMOND SERIES INTEGRATED AMPLIFIER

ROTEL

$3,249.00
$3,249.00
$6,499.00
Sold out
Tax included.

The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.




The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.

Digital inputs support 24-bit/192kHz audio streams. The asynchronous PC-USB input supports up to 32-bit/384kHz audio, decodes and renders MQA, and is fully certified Roon Tested.  A Moving Magnet Phono stage is also included for vinyl fans.

Front panel controls, back-lit IR remote and 2-line display ensure intuitive operation.

Ethernet, RS232,12V trigger and external remote input simplify integration with control systems.

The RA-6000 is available in both black and silver colors.




SPECIFICATIONS

Dimensions (W × H × D)
431 × 144 × 425mm
17" × 5.7" × 16"

Front Panel Height
3U / 132.6mm (5.25")

Power Requirements
230V, 50Hz

Power Consumption
500W

Standby Power Consumption
<0.5W

Net Weight
18.81kg (41.47lbs.)

BTU (4 ohms, 1/8th power)
1239 BTU/h
Maximum Power Output
350W/Ch (4Ω)

Continuous Power Output
200W/Ch (8Ω)

Total Harmonic Distortion
 (THD)
<0.0075%

Frequency Response
Line Level Inputs:
10Hz - 100kHz, ±0.5dB
Digital Inputs:
10Hz - 90kHz, ±2dB
Phono Input:
20Hz - 20kHz, ±0.5dB

S/N Ratio (IHF "A" Weighted)
Line Level Inputs: 103dB
Digital Inputs: 102dB
Phono Input: 80dB
Intermodulation Distortion
(60Hz:7kHz, 4:1)
<0.03%

Damping Factor
600

Input Sensitivity
Line Level Inputs (RCA): 340mV
Line Level Inputs (XLR): 540mV
Digital Inputs: 0 dBfs
Phono Input (MM): 5.2mV
Input Impedance
Line Level Inputs (RCA): 5.6kΩ
Line Level Inputs (XLR): 100kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ

Input Overload
Line Level Inputs (RCA): 3.5V
Line Level Inputs (XLR): 4.5V
Phono Input: 52mV

Preout Level
1.9V
Output Impedance
100Ω

Coax/Optical Digital Input Signals
LPCM (Up to 24-bit/192kHz)

PC-USB
USB Audio Class 2.0 (up to 32-bit/384kHz)*
*Driver installation required
MQA and MQA Studio (up to 24-bit/384kHz )
Roon Tested
