ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER
ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER
ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER
  • Load image into Gallery viewer, ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER
  • Load image into Gallery viewer, ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER
  • Load image into Gallery viewer, ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER

ROTEL RMB-1555 5-CHANNEL POWER AMPLIFIER

Vendor

ROTEL

Regular price
$1,959.00
Sale price
$1,959.00
Regular price
$2,799.00
Sold out
Unit price
per
Tax included.

With only slightly less power than its big brother, the RMB-1555 retains a very robust power supply to deliver 5 x 120 Watts per channel to medium and large home theaters.







The RMB-1555 is a remarkable multichannel amplifier with power output conservatively rated at 120 Watts per channel into 8 ohms (all channels driven!). With all but the most demanding speakers located in extraordinarily large rooms, the RMB-1555 exerts the kind of precise control that presents both nuance and bombast correctly from the faintest flute overtones to the subterranean rumble of an approaching apocalypse.

The RMB-1555 employs a high current, toroidal transformer matched to discrete output transistors with their higher thermal stability and freedom from the designed-in compromises that characterize their integrated circuit cousins. The Class AB amplifier configuration assures the best balance between power output and thermal efficiency.



SPECIFICATIONS

Dimensions (W × H × D)
431 × 188 × 454mm
17" × 7.5" × 17.9"

Front Panel Height
4U / 176.8mm (7")

Power Requirements
120V, 60Hz

Power Consumption
650W

Standby Power Consumption
0.5W

Net Weight
21.8kg (48lbs.)

BTU Rating (4Ω, 1/8th power)
1683 BTU/h
Continuous Power Output
120W/Ch (All channels driven, 8Ω)

Total Harmonic Distortion (THD)
(20Hz–20kHz) <0.03%

Frequency Response
10Hz - 100kHz +0.5, -3dB

S/N Ratio (IHF "A" Weighted)
116dB

Gain
26.5dB
Intermodulation Distortion (60Hz:7kHz, 4:1)
<0.03%

Damping Factor
180

Speaker Impedance
4Ω minimum

Input Sensitivity
1.5V

Input Impedance
12kΩ
