ROTEL RMB-1585MKII 5-CHANNEL POWER AMPLIFIER

Vendor

ROTEL

Regular price
$4,999.00
Sale price
$4,999.00
Regular price
Sold out
Unit price
per
Tax included.

RMB-1585MKII

Rotel’s new RMB-1585MKII 5-channel amplifier continues our heritage of producing high power, audiophile performance amplifiers for multi-channel systems.

The RMB-1585MKII delivers unparalleled performance with 5-channels of Rotel Class AB amplification rated at 210 Watts per channel into 8 ohms and an impressive 340 Watts per channel into 4 ohms with all channels driven.

Power5 x 340 Watts of
robust power, 4 Ohms

Class ABClass AB amplifier
design

TransformerMassive power supply
using Dual Toroidal
Transformers

CapacitorHigh-quality slit foil
capacitors

Rack MountRack ears included


Engineered with care.


Dimensions (W × H × D)
431 × 237 × 456mm
17" × 9.4" × 18"

Front Panel Height
5U / 221mm (8.75")

Power Requirements
230V, 50Hz

Power Consumption
1200W

Net Weight
37.4kg (82lbs.)

BTU Rating (4Ω, 1/8th power)
3317 BTU/h

Components


Continuous Power Output
210W/Ch (5 channels driven, 8Ω)
340W/Ch (5 channels driven, 4Ω)
440W/Ch (2 channels driven, 4Ω)

Total Harmonic Distortion (THD)
<0.03%

Frequency Response
10Hz - 100kHz, +0.1, -0.3dB

S/N Ratio (A Weighted)
120dB

Gain
26.9dB



Product Description

Rotel’s new RMB-1585MKII 5-channel amplifier continues our heritage of producing high powered, audiophile performance amplifiers for multi-channel systems.

Following Rotel's updated MKII design architecture, the RMB-1585MKII incorporates both circuit and component upgrades in the power supply and amplifier stages to delivering ultra-low distortion, signal isolation, and high-gain output power efficiently packaged in a single, multi-channel amplifier chassis.

The RMB-1585MKII delivers unparalleled performance with 5-channels of Rotel Class AB amplification rated at 210 Watts per channel into 8 ohms and an impressive 340 Watts per channel into 4 ohms with all channels driven.

The RMB-1585MKII is available in both black and silver colors.



More Specifications

Intermodulation Distortion (60Hz:7kHz, 4:1)
<0.03%

Damping Factor (1kHz, 8Ω)
223

Crosstalk/ Separation
> 55 db

Input Sensitivity
Unbalanced: 1.89V
Balanced: 4.7V

Input Impedance
Unbalanced: 12kΩ
Balanced: 50kΩ
