Features
- High power class A/B Stereo amplifier with 170W music power per channel.
- Metal Chassis.
- Toroid Transformer.
- Colour Fluorescent display for output level.
- 4mm binding posts for up to 4 speakers (2x2)
- Relay protected speaker output
- Pre-out, amp -in for equalizer or effects loop.
- Line level (microphone) output.
- Line-level input for CD and AUX connection.
- Low-pass filter sub-wooer output
- Two microphone 6.35mm inputs each with volume, balance. Low/mid/high EQ
- Microphone has DSP Echo effects with delay/feedback controls, level and high/low EQ
- Individual Music input channel with Low/mid/high EQ.
- Volume and balance – Select between stereo Aux line-line input and Stereo Bluetooth audio input; Master volume with low/mid/high tone controls
Specifications
- Amplifier Section
- Power consumption: 370w
- Audio output (program material) 170w+170w
- Input impedance 47ohms
- Input sensitivity: 200mV
- Bass Control: + - 15dB (100Hz)
- Mid Control +- 15dB (1khz)
- T.H.D less than 0.1%
- Frequency Response: 20Hz-20 kHz, -1dB
- Noise Ratio more than 90dB
- Power Source: 240V/50Hz
- Dimensions (W x H x D): 420 x 150 x 360mm
- Weight: 9kg
